4-way Indent Crimp Tool Banner

Deutsch DTM Connectors

Small
Contact Size: 20 (max 7.5 amps)
Wire Size: 16-22 AWG
Recommended Wire
Insulation Diameter: 1.35mm-3.05mm
Number of Cavities: 2, 3, 4, 6, 8, 12 cavity
Waterproof IP Ratings: IP67
Flame Retardant Grade: UL94 V-0
Temperature: -40~125°C
Deutsch DT Connectors

Medium
Contact Size: 16 (max 13 amps)
Wire Size: 12-20 AWG
Recommended Wire
Insulation Diameter: 2.23mm-3.68mm
Number of Cavities: 2, 3, 4, 6, 8, 12 cavity
Waterproof IP Ratings: IP67
Flame Retardant Grade: UL94 V-0
Temperature: -40~125°C
Deutsch DTP Connectors

Large
Contact Size: 12 (max 25 amps)
Wire Size: 10-24 AWG
Recommended Wire
Insulation Diameter: 3.40mm-4.32mm
Number of Cavities: 2, 4 cavity
Waterproof IP Ratings: IP67
Flame Retardant Grade: UL94 V-0
Temperature: -40~125°C

Comparison Between Deutsch Crimp Tools

Deutsch crimp tools are designed to be used with Deutsch connectors. Choose the most suitable one for your connection needs.

A table comparing the facets of 3 products
Facet	View details	View details	View details
Product Number
Product Number	ST2158	JRD-HDT-48	ACT-M202
Price exc. GST
Price exc. GST	Regular price exc. GST 6.204.000 VND	Regular price exc. GST 5.666.000 VND	Regular price exc. GST 4.927.000 VND
Wire Range
Wire Range	12-22AWG	12-22AWG	12-22AWG
Positioner Style
Positioner Style	Quick-change Turret (push button change between contact sizes)	Manually adjusting (manual adjust screw between contact sizes)	Manually adjusting (manual adjust screw between contact sizes)
Physical Size
Physical Size	Standard	Standard	Small form factor for tight areas
